Architectural Drawing Reviews

Working as part of the accessibility consulting team reporting to a multi-disciplinary design team, Marnie has participated in conducting comprehensive accessibility drawing reviews at 30%-60%-90% stages and developed comprehensive reports noting deficiencies and recommendations for remediation to achieve compliance. The drawing reviews were conducted as part of ensuring compliance with the most stringent requirement from multiple mandatory codes and standards. All recommendations were prioritized taking into consideration safety, mandatory compliance (OBC, COADS, AODA, NCC) and optional compliance (CSA, ADAAG, NBC).

Artist conceptual drawing of the Blair Ottawa LRT station. The drawing showing the east and west bound trains at the multi-level station.

Ottawa LRT

An evening view of the Ottawa Convention Centre (a.k.a. The Shaw Centre) taken from south of the building looking north. The photo shows the bowing exterior glazed wall of the 4 storey OCC. Adjacent to the OCC is the Westin Hotel, with the tower of the historic Frontenac Chateau Laurier also visible on the far left of the photo.

Ottawa Convention Centre (The Shaw Centre)

Photo of the Ottawa International Airport from the airside tarmac – a large aircraft is visible on the left side parked at a gate, and the Ottawa wordmark on the glass building façade is clearly visible.

Ottawa International Airport
